INSTALLATION GUIDE
EA10 SERIES
Start
End
Size
R/W
Name
Type
Units
SF
Contents
Description
40358 40358 1
R/W
Sensor LED Blink
Threshold
uint16
%
1 - 100
Current sensing module LED blink (over-range) threshold in percent of current
sensing module CT current rating of 20 A. Currents at or above this threshold
cause the current sensing module string LEDs to blink. Default is 100% (20 A).
40359 40359 1
R/W
Sensor LED On
Threshold
uint16
%
1 - 100
Current sensing module LED on (current flowing) threshold in percent of
current sensing module CT current rating of 20 A. Currents at or above this
threshold cause the current sensing module string LEDs illuminate. LED states
are reported in the SunSpec Basic String Combiner block, Vendor Event Flag
Register. Default is 3% (0.6 A).
40360 40360 1
R
Reserved
uint16
N/A
0
Unused register location. Reserved for future use.
40361 40376 16
R/W
Location Text String uint16
ASCII
N/A
Text
User writable string for storing the unit’s location or other information about the
unit. Up to 32 characters. Must be null terminated (unused bytes are all 0x00).
This string is returned as part of the response to the Modbus slave ID command.
Information on each of the attached current sensing modules.
Information for each of the current sensing modules.
40377 40377 1
R
Sensor 1 Unit ID
uint16
N/A
Sensor Unit ID:
ID Description
0 No unit detected or unit is not communicating. Module status LED is red.
1 8 channel, 20 A current sensor. Module status LED is green
40378 40378 1
R
Address
uint16
N/A
Sensor address on the EA10’s internal bus
40379 40379 1
R
OS Version
uint16
N/A
Sensor firmware version
40480 40481 2
R
Product Version
ASCII
N/A
Sensor product revision
40382 40386 5
R
Serial Number
ASCII
N/A
10 digit
Sensor serial number
40387 40387 1
R
Sensor 2 Unit ID
uint16
N/A
Sensor Unit ID:
ID Description
0 No unit detected or unit is not communicating. Module status LED is red.
1 8 channel, 20 A current sensor. Module status LED is green
40388 40388 1
R
Address
uint16
N/A
Sensor address on the EA10’s internal bus
40389 40389 1
R
OS Version
uint16
N/A
Sensor firmware version
40390 40391 2
R
Product Version
ASCII
N/A
Sensor product revision
40392 40396 5
R
Serial Number
uint16
N/A
10 digit
Sensor serial number
40397 40397 1
R
Sensor 3 Unit ID
uint16
N/A
Sensor Unit ID:
ID Description
0 No unit detected or unit is not communicating. Module status LED is red.
1 8 channel, 20 A current sensor. Module status LED is green
40398 40398 1
R
Address
uint16
N/A
Sensor address on the EA10’s internal bus
40399 40399 1
R
OS Version
uint16
N/A
Sensor firmware version
40400 40401 2
R
Product Version
ASCII
N/A
Sensor product revision
40402 40406 5
R
Serial Number
uint16
N/A
10 digit
Sensor serial number
