INSTALLATION GUIDE

EA10 SERIES

Status and Configuration Register Block

This block is implemented as a proprietary SunSpec device block. Register addresses are absolute in base 1 notation. Length is the number of 16 bit Modbus registers.

Start

End

Size

R/W

Name

Type

Units

SF

Contents

Description

40344 40344 1

R

C_SunSpec_DID

uint16

N/A

N/A

64001

Uniquely identifies this as a proprietary SunSpec format Modbus register map

40345 40345 1

R

C_SunSpec_Length uint16

Registers N/A

71

Block Length

40346 40346 1

R/W

Command Code

uint16

Code

Word

N/A

0

Always returns 0x0000 on a read.
Customer Command Codes:

Dec

Hex

Description

30078

0x757E

Clear all accumulators to 0.

40347 40347 1

R

Hardware Revision

uint16

N/A

0

4 bit hardware revision:

Bit

Description

0-3

Hardware Revision

4-15

unused

40348 40348 1

R

RS FW Revision

uint16

N/A

Reset System Firmware Version

40349 40349 1

R

OS FW Revision

uint16

N/A

Operating System Firmware Version

40350 40351 2

R

Product Revision

ASCII

N/A

Product Revision

40352 40352 1

R

Boot Count

uint16

N/A

Count of Boot Cycles

40353 40353 1

R

DIP Switches

uint16

N/A

All 16 DIP switches:

Switch

Function

87654321 Address
87654321 Reverse, Parity, Baud Rate (see DIP Switch Settings, page 5)

40354 40354 1

R

# Detected current

sensing modules

uint16

N/A

0 - 4+

Number of current sensing modules detected on the bus by analog

measurement.

40355 40355 1

R

# Communicating

current sensing

modules

uint16

N/A

0 - 4

Number of current sensing modules that the communications unit is able to

communicate with. If all modules are active and communicating, this number

will match the previous register, and the user can assume all status LEDs are

green. If one or more modules is not communicating, these values will not

match, and the affected module status LED is red.

40356 40356 1

R

System Status

uint16

N/A

Bit Map

Status bit map:

Bit

Hex

Description

0

0x0001

Actual state of amperage sign reversal and sensing

module LED color state. Controlled by DIP switch if

configuration register (next register) bit 1 is 0, or

configuration register bit 0 if bit 1 is asserted.

1-15

unused

40357 40357 1

R/W

System

Configuration

uint16

N/A

Configuration bit map:

Bit

Hex

Description

0

0x0001 Reverse amp sign and sensing module LED color.

Has no effect if bit below is 0.

1

0x0002 Override Reverse DIP Switch. If this bit is

0, the Reverse Current DIP switch on the

communications unit controls the state of the

reverse amp sign bit in the status register. If this

bit is set to a 1, the state of the bit above controls

sign reversal.

2-15

unused
