8
Pan Pan Pan Pan Pan
Place the pan into the hole in the weighing
mechanism.
AC ADAPTER
RECEPTACLE
PAN
SPILL RING
LEVEL INDICATOR
LEVELING FEET (2)
AC Adapter AC Adapter AC Adapter AC Adapter AC Adapter
Plug the molded connector of the AC
Adapter into the receptacle at the rear of
the balance. Plug the AC Adapter into a
convenient ac outlet. When power is
applied to the balance, it will begin a 60
second self test cycle. During this time, if
the balance is turned ON, the display will
count down from 60 and display the word
CHEC.
Leveling the Balance Leveling the Balance Leveling the Balance Leveling the Balance Leveling the Balance
The balance is equipped with a level
indicator on the rear and two adjust-
able leveling feet. Adjust the level-
ing feet until the bubble appears in
the center circle of the indicator.
