Using menus to configure the balance – Ohaus AS Series Electronic Balances User Manual

Page 12

USER

RESET

Yes, No

0, 1

1, 2, 3

STB

.5d, 1d

1d, 2d, 5d

AUTO-0

OFF , .5d ,

.5d ,

.5d , 1d, 3d

END

SETUP

LFT

On, Off

Off

LOCSW

Calibration
User
Setup
Print

End

END

CAL

SPAN

LIN

END

USING MENUS TO CONFIGURE THE BALANCE

Analytical Standard balances contain four display menus which enable you to calibrate
and configure the balance for your specific operating requirements.

Calibration Menu:

Calibration Menu: Used to calibrate the balance for span or linearity.

User Menu:

Used to adapt the balance to environmental conditions.

Setup Menu:

Used to enable or disable different balance features.

Print Menu:

Used to configure the RS232 Interface.

Functions not allowed on verified balances have shaded backgrounds.

NOTE:
PRINT menu appears only
when RS232 option is in-
stalled.

next selection

select

displayed item

To access a menu, press and hold

until desired menu appears, then release it.

Original factory default settings are shown in boldface type.

Use these buttons to step through menus and select submenus:
