8 Gas sampling and gas conditioning technology 2.7a-ME
7 TECHNICAL DATA
Gas Sample Probe Series SP® SP180-H
Part No. 02S1800
Weather protection shield yes
Mounting outdoors yes
Sample tube Type SP210/SS, stainless steel 316Ti, length 1 m* optional*
Sample temperature max. 600 °C*
Sample pressure 0.4 to 2 bar abs.
Ambient temperature -20 °C to +60 °C
Recommended for dust loadings up to 1 g/m 3 *
Filter chamber volume 70 ml
Filter element S-2K, filter porosity 2 μm, ceramic
Probe heating temperature +180 °C self-regulating
Ready for operation after 2 hours
Temperature alarm contact, alarm point <160 °C, NO
Temperature alarm, contact rating 250V-3A AC, 30V-3A DC
Connection sample outlet 1/4"-NPT inside, with 6 mm (DN4/6) Swagelok tube connector
Power supply 110 up to 240V 50 / 60Hz
Power consumption start up: 400VA, usual: 100VA, (fuse 6A)
Electrical connection terminals max. 2,5 mm 2 , cable glands 1 x M20x1,5 and 1 x M16 x
1,5
Electrical equipment standard EN 61010, EN 60335-1
Degree of protection IP54, EN 60529
Mounting flange DN65 PN6,B stainless steel 316Ti
Material of sample contacting parts SS 316 / 316Ti, FPM, ceramic
Weight 7,5 kg
Option
Part No.: 02 S 9200
Insitu probe tube out of stainless steel 316Ti type SP210/SS,
connection G3/4" o, ø 10/12, length 1 m*, incl. flange gasket.
* Standard, other versions on request.
P und T90 at flow of: 100 200 500 Nl/h
P pressure loss with new filter element S-2K: 4 7 15 mbar
T90 time-without sample tube/prefilter- 4,0 2,5 <1,0 Sec.
8 APPLICATIONS
The electrically heated M&C gas sample probe SP180-H is used for continuous gas sampling in
processes with dust densities of up to 1g/m³, operating pressure of up to max. 6 bar abs.,
temperatures of up to a maximum of 600°C or for high gas humidity. Thanks to its compact design it
requires only limited space. The gas sample probe SP180-H is equipped with a new protective cover
and can be used for outdoor mounting.
