8
Gas sampling and gas conditioning technology 6-5.1.1-ME
7 TECHNICAL DATA
3/2-Way Valves V3/2-H V3/2-H/PE MV3/2-H
Part number 03V3000 (a) 03V3010 (a) 03V2000 (a)
Position identification no yes no
Nominal width / C
v
DN7 / 1,7 DN4 / 0,4
Operating pressure max. 30bar max. 2bar
Sample gas temperature max. +180°C
Ambient temperature -25°C to +60°C
Storage temperature -25°C to +80°C
Gas connections
Tube connectors Ø 6mm, optional Ø ¼” type Swagelok ®
Temperature controller Capillary thermostat with high temperature limiter and low tempera-
ture alarm; integrated in electrical connection box
Operating temperature 0°C
– 180°C (set at factory) adjustable
Dial thermometer Range 50°C – 250°C
Temperature alarm Alarm point

T -30°C to T
set
Contact rating Voltage free change-over contact, 250V 3A~, 0,25A=
Position identification Voltage free change-
over contact, 250V
AC
1A
Power supply 230V 50Hz, 115V 60Hz (a)
Power supply solenoid valve 24V
DC
15W
Power consumption 350VA
Electrical connections Terminals 4mm 2
2 x PG13
Terminals 4mm 2 , 3 x PG13
Protection / Electrical stan-
dard IP54 (EN 60529) / EN 61010, EN 60519-1
Dimensions (wxhxd) / 350x320x150mm 350x320x150mm
Weight 7,5kg 8kg
Dead volume approx. 5cm
3
Materials of sample wetted
parts Stainless steel 316Ti, PTFE Stainless steel
316Ti, FPM,
FFKM
Mounting Wall mounting
