Gas sampling and gas conditioning technology 6-5.1.1-ME
12 MOUNTING

Loosen the four clamps on top and at the bottom.

Remove the cover of the heated 3-way-valve type V3/2- H… and MV3/2-H.

Remove the aluminium lid by loosening the two screws.

Connect the sample lines to the fittings.
N O T E !
Make sure that the connection is leak proof!

Put the aluminium lid back again and screw it.

Put the cover of the heated 3-way-valve on top again and close the clamping devices.
13 ELECTRICAL CONNECTION
W A R N I N G !
When connecting the equipment, please ensure that the supply
voltage is identical with the information provided on the type plate.
N O T E !
Attention must be paid to the requirements of IEC 364 (DIN VDE
0100) when setting high-power electrical units with nominal volt-
ages of up to 1000 V, together with the associated standards and
stipulations.
A main switch and matching fuse must be provided externally!
The main circuit must be equipped with a fuse corresponding to
the nominal current (over current protection), for electrical details
see technical data.

Remove the lid of the electrical connection box. The electrical connection layout is located in the
lid. Insert the mains cable (min. 3 x 1.5 mm²) through the cable gland and connect to the appro-
priate terminals.

Insert the signal cable through the cable gland and connect to the appropriate terminals. Screw
lid back on.
