Temperature classes for sampling from Ex-zone 0
Options sample tubes
Options
Version
Part No.
Length 1m, material SS316Ti, temperature max. 600 °C
SP2000/SS
20 S 9065
Length 1m, with volume displacer, material SS316Ti, Temperatur max. 600 °C
SP2000/SS-Vm
20 S 9067
Length 1m, material Hastelloy-C, temperature max. 900 °C
SP2000/HC
20 S 9090
Length 1m, material Kanthal, temperature max. 1300 °C
SP2000/KA
20 S 9080
Length 1m, material Incoloy 956, temperature max. 1200 °C
SP2000/IC
20 S 9072
Type
Possible Options
Marking
Temperature class
Max. process gas temp. (°C) at
the probe entry
Max. surface temperature (°C)
SP3100V
II 1 G / 2 GD
T6
≤ 68
68
SP3100V
II 1 G / 2 GD
T5
≤ 80
80
SP3100V
II 1 G / 2 GD
T4
≤ 108
108
SP3100V
/HEX4..
II 1 G / 2 GD
T3
≤ 160
160
SP3100
II 1 G / 2 GD
T2
≤ 200
200
Type
Possible Options
Marking
Temperature class
Max. process gas temp. (°C) at
the probe entry
Max. surface temperature (°C)
SP3100V
II 1 G / 2 GD
T6
≤ 80
80
SP3100V
II 1 G / 2 GD
T5
≤ 95
95
SP3100V
/RS, /HEX4-135
II 1 G / 2 GD
T4
≤ 130
135
SP3100
/HEX4-180
II 1 G / 2 GD
T3
≤ 195
195
SP3100
/RS, HEX1..
II 2 G / 2 GD
T3
≤ 195
195
SP3100
/RS
II 2 G / 2 GD
T2
≤ 200
200
Temperature classes for sampling from Ex-zone 1 or 2
For choosing the adequate sample tube see data sheet 2-1.1.0.6 as well
