2.10
Technical specifications and illustrations are without
obligation, subject to modifications. 10.04/11.12
Gas sample probe type SP3100V (up to 185 °C) SP3100 (more than 185 °C)
Option heating type HEX1 HEX1-1
Part No. 20S9038 (a)
Mounting controller inside the Ex-zone 1, 2
Control electronic
Power supply 230V 50/60Hz or 115V 50/60Hz (a)
Electrical connection 3 x 1,5mm 2
Marking
II 2 G EEx d e ib IIC T3*, other temperature classes on request
Power 400W
Case protection IP54; EN60529
Temperature 0 - 180 °C T3 or 0 - 135 °C T4
Ambient temperature -20 °C to +40 °C
Low temperature alarm contact <120°C, 1 change-over contact, 230V 1,5AAC, 0,5ADC
Option 2-way-ball valve in the probe
entrance /VA
Part No. 20S9050
Operating temperature -20°C up to +185°C
Option 2/3-way-ball valve in the probe
entrance /3VA
Part No. 20S9325
Backflush / Test gas connection 6mm tube
Operating temperature -20°C up to +185°C
Option pneum. drive for ball valve /VA
o. /3VA MS1
Part No. 20S9055
Connection control air G1/4” i
Pressure control air 5-10 bar
Temperature class T4
Option second sample gas outlet /2X
Part No. 20S9015
Connection 1/4” NPT i
Optionƒspunƒglassƒcartridge /FW
Part No. 20S9047 20S9046
Material SS316Ti, Novapress SS316Ti, Graphite
Technical Data
* Standard, ** optional
∆P and T90 at flow of: 100 200 500 1000 1500 Nl/hr
∆P with new filter element F-3SS150 0,006 0,012 0,040 0,110 0,215 bar
∆P with new filter element S-2K150 0,003 0,005 0,02 0,058 0,135 bar
T90-time for SP3100 without tube 6 3,5 1 <0,5 <0,5 s
Differential pressure and T
90
-time
