2.10
* Standard, ** optional
Technical Data
Technical specifications and illustrations are without
obligation, subject to modifications. 10.04/11.12
Gas sample probe type SP3100V (up to 185 °C) SP3100 (more than 185 °C)
Part No. 20S5605 20S5600
Weather protection shield yes
Filter housing material Stainless steel 316 / 316Ti
Sealing materials Graphite, FPM Graphite
Probe flange sealing material Graphite
Pre-filter / sample tubes optional, see data sheet 2-1.1.0.6 and 2-1.1.0.8
Sample pressure max. 0,5-6 bar abs
Ambient temperature -20 °C to +60 °C
Permissible process gas temperature depending on the temperature class, however max. 200°C at the probe entry
Filter chamber volume 120 cm 3
Filter element, porosity F-3SS150= stainless steel*, 3 micron S-2K150= ceramic**, 2 micron
Sample gas outlet connection 1x 1/4“ NPTi for max. 8mm-tube connectors
Connection gas outlet at option RS 6 mm Swagelok connector
Mounting flange DN65 PN6, FormB, SS316Ti* >DN or ANSI possible**
Weight 7 kg
Marking
II 1G/2GD -20°C ≤ Ta ≤ +60°C EXAM BVS 04 ATEX H 045X
Marking with option RS
II 2G/2GD -20°C ≤ Ta ≤ +60°C EXAM BVS 04 ATEX H 045X
Option back purge unit type RS RS
Part No. 20S5560 (a)
Power supply 230V 50/60Hz 9W or 115V 50/60Hz 9W (a)
Electrical connection cable 3x1mm 2
Marking
II 2GD EEx m II 135°C
Connection G1/2” at the buffer vessel
Max. back purge pressure 6 bar abs
Volume buffer vessel 2 liters
Ambient temperature -20°C to 60°C
Option heating type HEX4 HEX4-135 HEX4-180
Part No. 20S5510 20S5520
Mounting controller in the Ex-zone 1, 2, 21, and 22
Control self-regulating
Power supply 115V - 230V 50/60Hz
Electrical connection cable gland, terminal range 7 - 12mm, terminals max. 4mm 2
Marking
II 2 G EEx em T3..T4 / II 2 D IP66 135°C...180°C EXAM BVS 04 ATEX E 253
Case protection IP66; EN60529
Power 400W
Max. temperature 120 °C 160 °C
Min. temperature 90 °C 120 °C
Ambient temperature -20 °C to +60 °C
Low temperature alarm contact <60°C, 1 contact MC-NO, 230V 1,5A AC, 0,5ADC <100°C, 1 contact MC-NO, 230V 1,5A AC, 0,5ADC
Option heating type HEX1 HEX1-3
Part No. 20S9037 (a)
Mounting controller outside the Ex-zone
Control electronic
Power supply 230V 50/60Hz or 115V 50/60Hz (a)
Electrical connection 3 x 1,5mm 2
Marking
II 2 G EEx d ib IIC T3*, other temperature classes on request
Power 400W
Case protection IP54; EN60529
Temperature 0 - 180 °C T3 or 0 - 135 °C T4
Ambient temperature -20 °C to +40 °C
Low temperature alarm contact <120°C, 1 change-over contact, 230V 1,5AAC, 0,5ADC
