Issue 6.0.B IPBrowse Version 6.0 – User Manual
EVS Broadcast Equipment – November 2012
76
9. ShuttlePRO Functions
9.1.1 Introduction
ShuttlePRO has a Jog wheel and a Shuttle ring, and fifteen buttons. The two top rows of
buttons on the ShuttlePRO series have labels for quick reference as to which functions
each button is designed to perform.
9.1.2 Button Configuration
The button configuration is hard coded. Buttons may have CTRL or SHIFT from the
keyboard as a modifier to change the button function. These functions are shown in red
for CTRL and blue for SHIFT in the diagram below.
Details on the button functions are included in the respective sections of the current
manual. The diagram below is a quick reference guide to the location of the functions.
