IPBrowse Version 6.0 – User Manual

EVS Broadcast Equipment – November 2012

Issue 6.0.B

5

Area

Description

3.

Quick Text
Search Area

The Quick Text Search area provides functions to perform
quick text searches. Later on, users will be able to save
applied filters or recall and apply saved filters to the current
search.

See section 2.3.

4.

Elements Grid
or List

The Elements grid/list displays all the items included in the
selected tree branch or resulting from a search. Two different
views are available: grid or list.

See section 2.6.

A bottom bar shows the number or results found.

5.

Toolbar

The toolbar on the top of the Elements grid/list provides a
series of buttons and menus to define options related to the
elements view, transfer monitoring, clip creation and password
management.

See section 2.5.

6.

Player Pane

This pane is used to preview the loaded item, to create clips
from the media and to send clips to a selected bin.

See section 2.7.

7.

Bins Pane

This pane may contain several bins. It is used to sort clips
within the bins. The transfer of clips to targets is requested
from the Bins pane.

See section 2.8.

The layout of the IPBrowse can be adapted to users’ needs:

the Tree View and the Advanced Search Pane can be hidden by clicking the

split

box or shown by clicking the

split box.

most of the panes can be enlarged or reduced by moving the intersection line
between them
