IN4/OUT1 IN3/OUT2 IN2/OUT3 IN1/OUT4
#REC #PLAY
Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link
0 1 PLAY1 MIX1
1 1 PLAY1 MIX1 REC1
2 1 PLAY1 MIX1 REC2 REC1
3 1 PLAY1 MIX1 REC3 REC2 REC1
0 2 PLAY1 MIX1 PLAY2 MIX2
1 2 PLAY1 MIX1 PLAY2 MIX2 REC1
2 2 PLAY1 MIX1 PLAY2 MIX2 REC2 REC1
0 3 PLAY1 MIX1 PLAY2 MIX2 PLAY3 MIX3
1 3 PLAY1 MIX1 PLAY2 MIX2 PLAY3 MIX3 REC1
0 4 PLAY1 MIX1 PLAY2 MIX2 PLAY3 MIX3 PLAY4 MIX4
Example: 3REC + 1PLAY
The BNC connectors to be used as record and play channels in a standard 3REC 1PLAY
configuration need to be cabled as shown below:
XS 6U Servers
Available Standard Configurations
IN6/OUT1 IN5/OUT2 IN4/OUT3 IN3/OUT4 IN2/OUT5 IN1/OUT6
#
REC #
PLAY Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link
1 0 REC1
2 0 REC2 REC1
3 0 REC3 REC2 REC1
4 0 REC4 REC3 REC2 REC1
5 0 REC5 REC4 REC3 REC2 REC1
