Record key
Description Changes the function of the RECORD key on the Remote
Panel, as described below.
Values The following values are possible:
• Start REC+Live:
Pressing the RECORD key starts the record process and
switches to LIVE mode.
• Live:
Pressing the RECORD key only switches to last recorded
picture, but the record is not restarted if it has been
previously stopped by the operator.
Default value Start REC+Live
Pointing device
Description Specifies the pointing device connected to the EVS server, and
initializes it.
If the tablet is not properly calibrated, this function will re-
initialize it.
If you use the touch screen, it must always be connected to
RS422 port #6 of the server, and defined as such in the
Channels tab, Port settings.
Values Tablet / Touch Screen
Default value Tablet
