Command description Command key
Activating the Advanced display mode
Coming back to the Basic display mode
Applying changes
Canceling changes
In Server- and Web-Based Interfaces
Display and Checks of Modified Values
Once modified, the field values are displayed in blue color as long as the changes have
not been applied. No check on inconsistent or incompatible field values are performed at
that stage.
When you apply the changes, the following occurs:
• The values you have modified are checked. If setting values are inconsistent, you will
get an error message at that stage.
• The validated values return to the standard color.
• The inconsistencies are displayed as follows:
◦ Inconsistent values are displayed in red.
◦ A warning message tells you which field value is problematic.
◦ The page containing the inconsistent field value is then displayed when you use
the server-based application.
3.1.4. Overview of the Setup Menus in the Remote
Panel
Introduction
When you work in XSense mode, the Technical and Operational Setup menus available
on the Remote Panel allow you to define:
• the commonly used technical settings in the Technical Setup menu
• all operational settings in the Operational Setup menu.
The values assigned to the settings are saved as soon as they are modified.
Accessing the Technical Setup Menu
To access the Technical Setup menu, press F0 from the Main Setup page.
The Technical Setup menu opens on the 1 st page.
