3.2. Supported Configurations
3.2.1. General Information on Supported
Configurations
Overview on Supported Configuration Types
An XS server, equipped with V3X or COHX boards, supports the following configurations
types:
• standard SD/HD configurations
• 3D/1080p configurations
Note
The feature 'Mix on one channel' for play channels is available on the
SD/HD configurations with V3X boards.
The feature 'Two recorders per codec module' is not available.
Number of Record and Play Channels
The number of record and play channels for a given configuration is defined in the
Channels tab, in the Base settings. See section "Base Settings" on page 83.
This section presents the number of channels available on an XS server.
The number of record and play channels that can be operated vary based on the chassis
type. The following table shows the minimum and maximum number of channels that can
be operated:
6U
(V3X )
5U
(V3X or COHX)
Max. # channels 6 4
Min. # REC 0 0
Max. # REC 6 4
Min. # PLAY 0 0
Max. # PLAY 6 4
