2.4 Expansion Slots (PCI and PCI Express Slots)
There is 1 PCI slot and 5 PCI Express slots on this motherboard.
PCI Slot: PCI slot is used to install expansion cards that have the 32-bit PCI
interface.
PCIE Slots:
PCIE1 (PCIE x16 slot) is used for PCI Express x16 lane width graphics
cards.
PCIE2 (PCIE x1 slot) is used for PCI Express cards with x1 lane width
cards, such as ASRock Game Blaster, Gigabit LAN card, SATA card.
PCIE3 (PCIE x16 slot) is used for PCI Express x4 lane width graphics
cards.
PCIE4 (PCIE x16 slot) is used for PCI Express x16 lane width graphics
cards.
PCIE5 (PCIE x16 slot) is used for PCI Express x8 lane width graphics
cards.
PCIE Slot Configurations
PCIE1 PCIE2 PCIE3 PCIE4 PCIE5
Single Graphics Card
x16
N/A N/A N/A N/A
Two Graphics Cards in
x16 N/A N/A x16 N/A
CrossFireX
TM
or SLI
TM
Mode
Three Graphics Cards in x16 N/A N/A x8 x8
3-Way CrossFireX
TM
or
3-Way SLI
TM
Mode
1. In single VGA card mode, it is recommended to install a PCI Express
x16 graphics card in the PCIE1 slot.
2. In CrossFireX
TM
mode or SLI
TM
mode, please install the PCI Express
x16 graphics cards in PCIE1 and PCIE4 slots. Both these two slots
will work at x16 bandwidth.
3. In 3-Way CrossFireX
TM
mode or 3-Way SLI
TM
mode, please install the
PCI Express x16 graphics cards in PCIE1, PCIE4 and PCIE5 slots.
PCIE1 will work at x16 bandwidth, while PCIE4 and PCIE5 slots will
work at x8 bandwidth.
4. Please connect a chassis fan to the motherboard’s chassis fan
connector (CHA_FAN1, CHA_FAN2 or CHA_FAN3) when using
multiple graphics cards for better thermal environment.
