seekTech sR-20
SR-20 Components
Figure 1: SR-20 Components
Battery Compartment
Serial Port Connector
USB Connector
Icon Reference
Note: USB/ Serial Ports are
for loading new software
Serial Number Label
Antenna Mast
Upper Antenna
Node
Folding Joint
Lower Antenna
Node
Guidance
Antennas
Display Screen
Keypad
Handle
Speaker
Folding Mast Snap
