seekTech sR-20
Pictogrammen en symbolen
Figuur 38: pictogrammen en symbolen
DISPLAY ICONS DISPLAY ICONS (Con’t) MENU ICONS
Sonde Frequency
Active Trace Frequency
Signal Angle Indicator
Audio Level Radio Frequency
Passive Line Trace Frequency Battery Level
Measured Distance/Depth
Signal Strength
Factory Default Reset
Menu Check Box
Go Up One Level
(press menu key)
No Sonde Present
No Power Present
No Trace Present
No RF Present
Display Elements
Frequency Selection Control
Line Direction Gradient
Tracing Line
Pass Banwidth
Distortion Line
Equator
Pipe Direction
KEYPAD ICONS
Menu Navigation/Signal Focus/Proximity Threshold Control
Menu Navigation/Signal Focus/Proximity Threshold Control
Menu Selection
SondeMode: Force Depth/Re-center Audio
Line Trace Mode: Force Depth, Force current, Re-center Audio
Signal Strength Proximity Setting: Force Map On
Power ON / OFF Key
Menu Key
Frequency Key
Sound Key
Proximity Threshold Control
Milliamp, Current
Menu Timeout Counter
Pole Icon
Proximity Signal
Tools Menu
Backlight settings
Screen Contrast Adjust
Depth Greater Than 3 Feet/1 Meter Threshold
Depth Greater Than 10 Feet/3 Meter Threshold
Depth Greater Than 30 Feet/10 Meter Threshold
Depth Greater Than 99 Feet/30 Meter Threshold
Low Battery Warning (flashing)
Information Screen
Level Pointer
(Signal Strength)
Watermark
(Signal Strength)
Aan/uit-toets
Menutoets
Frequentietoets
Geluidtoets
SCHERMPICTOGRAMMEN (vervolg)
Nabijheidssignaal
Signaalsterkte
Audioniveau
Batterijniveau
Waarschuwing voor bijna lege
batterijen (knippert)
Niveau-aanwijzer
(signaalsterkte)
Waterpeilmarkering
(signaalsterkte)
Geen sonde aanwezig
Geen stroom aanwezig
Geen tracering aanwezig
Geen RF aanwezig
Doorlaatbandbreedte
Leidingrichtingsgradiënt
SCHERMPICTOGRAMMEN
Sondefrequentie
Actieve-traceringsfrequentie
Radiofrequentie
Passieve leidingtracering
Gemeten afstand/diepte
Signaalhoekindicator
Milliampère, stroom
nabijheidsdrempelinstelling
Poolpictogram
Traceerlijn
Vervormingslijn
0-lijn
Buisrichting
MENUPICTOGRAMMEN
Fabrieksinstellingen herstellen
Menuaankruisvakje
Tools-menu
Instellingen achtergrondverlichting
Schermcontrast regelen
Displayelementen
Frequentieselectie-instelling
Informatiescherm
Menu-timeout-teller
Eén niveau naar boven gaan
(druk op Menu-toets)
TOETSENBORDPICTOGRAMMEN
Menu Navigatie/Signaalfocus/Nabijheidsdrempelinstelling
Menuselectie
Sondemodus: Diepte forceren/Audio opnieuw centreren
Leidingtraceermodus: Diepte forceren, stroom forceren, audio opnieuw centreren
Signaalsterktenabijheidsinstelling: forceer kaart aan
Menu Navigatie/Signaalfocus/Nabijheidsdrempelinstelling
Diepte groter dan 3 voet/1 meter drempel
Diepte groter dan 10 voet/3 meter-drempel
Diepte groter dan 30 voet/10 meter drempel
Diepte groter dan 99 voet/30 meter-drempel
