seekTech sR-20
Componentes del SR-20
Figura 1: Componentes del SR-20
Compartimiento de las pilas
Conector de puerto en serie
Conector USB
Referencia de iconos
Nota: los puertos USB/serie son para la
instalación de nuevo software
Etiqueta de número de serie
Mástil de la antena
Nodo superior de
la antena
Unión plegable
Nodo inferior de
la antena
Antenas de
dirección
Pantalla de
visualización
Panel de mandos
Empuñadura
Altavoz
Encaje del mástil plegable
