Description of parameters
Factory settings
24 MI FF 24 FF 24 MI 24
F01
Type of boiler
10 = sealed chamber 20 = atmospheric chamber
10 10 20 20
F02
Gas used
00 = METHANE
01 = LPG
02 = METHANE (WITH DIAPHRAGM)
02
F03
Hydraulic system
00 = instantaneous appliance
03 = appliance with external storage boiler
04 = appliance for heating only
13 = preheating (24h)
14 = preheating (1h)
13 04 13 04
F04/ F05
Setting programmable relays 1 and 2 (See SERVICE instructions)
00 = no associated function
00
F06
Maximum CH setpoint (°C)
00 = 85°C - 01 = 45°C (function unavailable)
00
F07 DHW inlet priority configuration 00 01 00 01
F08 CH max. output (0-100%) 100
F09 DHW max. output (0-100%) 100
F10 Min. heating output (0-100%) 00
F11
Delay prior to new ignition in CH mode
(00-10 minutes) - 00=10 seconds
03
F12 Diagnostics (See SERVICE Instructions) --
F13-F14-F15 Factory settings 00
F16
Anti-legionella function (with F03=03)
00 = disabled
55...67 = enabled (setpoint °C)
00
F17
CH pressure sensor selection
00 = hydraulic pressure sensor
01 = hydraulic differential pressure sensor
00
F18 Manufacture information 00
21. PARAMETER SETTINGS
To set the boiler parameters, press (
–
) and (
–
) together and hold down for at least 6 seconds. When the function is
activate, the “ F01” appears on the display alternating with the value of the parameter shown.
Edit parameters
• Press (
+/–
) to scroll through the parameters;
• Press (
+/–
) to edit each parameter;
• Press ( ) , to save the changes. “ MEM” appears on the display;
• Press (
i
) , to exit without saving. “ESC” appears on the display.
22. ADJUSTMENT AND SAFETY DEVICES
The boiler has been designed in full compliance with European reference standards and in particular is fitted with the
following:
• Air pressure switch (model 24 MI FF - 24 FF)
This device only allows the burner to ignite if the exhaust flue duct is in perfect working order.
In the event of one or more of the following faults:
• flue terminal obstructed
• venturi tubes obstructed
• fan blocked
• venturi tube connection - pressure switch tripped
the boiler remains on standby and error code E03 is displayed (see table in section 10).
• Fumes thermostat (model 24 MI - 24)
This device has a sensor positioned on the left section of the fumes hood and shuts off the gas flow to the main burner
if the flue is obstructed and/or if there is no draught.
In these conditions the boiler shuts down and displays error code E03 (section 10).
After eliminating the problem, press button ( ), for at least 2 seconds to re-ignite immediately.
It is forbidden to disable this safety device
