Prestige 153/153X WAN Bridge/Routers
Remote Node Configuration 4-15
4.2 Leased Line Support
A leased line provides a connection that is always up without dialing and modem negotiation,
which can take tens of second. The WAN port on the Prestige allows you to connect a leased line
modem (async). Obviously, the Connection Type of the WAN port must be selected as [Leased]
in Menu 2.1 - Async WAN Port Setup.
Please note that synchronous device support is available only on WAN port 1 and 2 of Prestige
153X.
4.2.1 Dial-up Backup for Leased Line
If you have a dial-up line in addition to the leased line, you can use the dial-up line as a backup
for the leased line in the event that the leased line is down. When the leased line connection
drops, your Prestige will select an available modem to place a phone call to establish a backup
connection. When the leased line is up again, your Prestige will drop the backup link.
4.2.2 Leased Line Remote Node Profile
From Submenu 11.1.2, select [Leased] in the Connection Type field to go to Submenu 11.1.2 -
Remote Node Profile for Leased Line application, as shown in Figure 4-5.
Figure 4-5. Menu 11.1 - Remote Node Profile for Leased Lines
Menu 11.1 - Remote Node Profile
Rem Node Name= ?
Active= Yes
Connection Type= Leased
Leased Ports = ?
Incoming:
Rem Login = ?
Rem Password = ?
Outgoing:
My Login= ?
My Password= ?
Authen= CHAP/PAP
Backup Line Call Direction= Both
Device Type= 56K Modem
Pri Backup Phone #= ?
Sec Backup Phone #=
Route= IP
Bridge= No
Edit PPP Options= No
Rem IP Addr= ?
Edit IP/IPX/Bridge= No
Session Options:
Input Filter Sets=
Output Filter Sets=
Idle Timeout(sec)= 300
Press ENTER to CONFIRM or ESC to CANCEL:
Press Space Bar to Toggle.
