Prestige 153/153X WAN Bridge/Routers
Hardware Installation & Initial Setup 2-19
Figure 2-12 shows the menu for Sync/Async WAN port configuration .
Figure 2-12. Prestige 153X Menu 2.1 - Sync/Async WAN Port Setup
Table 2-6 describes how to configure the Prestige 153X Async WAN ports.
Table 2-6. Prestige 153X Sync/Async WAN Port Setup Menu Fields
Field Description Example
Modem Name Enter a descriptive name for the WAN device connected to this port. ZyXEL
Active Set to [Yes] to activate the WAN port. Press space-bar
to toggle
[Yes]/[No]
Connection
Type Select the line and the port type combination. Select [Switch] for dial-up
line or [Leased] for leased line. Select [Async] if the connection
between the WAN device and the WAN port is asynchronous ; [Sync]
otherwise.
Note that synchronous devices are allowed only on leased lines
Press space-bar
to toggle
[Switch-Async]
[Leased-Async]
[Leased-Sync]
Menu 2.1 - Sync/Async WAN Port Setup
Modem Name= ZyXEL
Active= Yes
Connection Type= Switch-Async
Phone Number=
Clock Source= Internal/External
Device Type= 56K Modem
Port Speed= 115200
AT Command String:
Init= ats0=0
Advanced Setup= No
Press ENTER to Confirm or ESC to Cancel:
