Prestige 153/153X WAN Bridge/Routers
Hardware Installation & Initial Setup
2-3
2.3 Connect your WAN Bridge/Router
2.3.1 Prestige 153 Connections
Figure 2-1.
Prestige 153 Connections
POWER
LAN
WAN-1
WAN-2
WAN-3
CONSOLE
Ethernet LAN
Modem / ISDN TA
Modem / ISDN TA
Power
Adapter
Power
Outlet
Modem / ISDN TA
Modems
or
ISDN TAs
Computer
or
PSTN/ISDN Network
