Page 34
Prestige 153/153X WAN Bridge/Routers
2-4
Hardware Installation & Initial Setup
2.3.2 Prestige 153X Connections
Figure 2-2.
Prestige 153X Connections
POWER
LAN
WAN-1
WAN-2
WAN-3
CONSOLE
PSTN/ISDN Network
Fractional T1/E1
Computer
or
Ethernet LAN
Power
Adapter
Power
Outlet
Modem / ISDN TA
Modem / ISDN TA
Modem / ISDN TA
Modem
ISDN TA
CSU/DSU
Modem
ISDN TA
CSU/DSU
Modem
ISDN TA
