DocuColor 5000 Administrator Guide
3-12
3. Profiles
e. Select Start. The UI displays this message after the
test prints are printed:
f. Retrieve your prints.
g. Discard the first few prints, as inconsistency tends to
be greater with these images.
19.
Evaluate the test prints by holding your 2 Sided output at
eye level near a light source. This will allow you to see the
registration marks for both Side 1 and Side 2 of the output.
a. If you determine that the registration between Side 1
and Side 2 is unacceptable and needs adjusting,
repeat this procedure starting at
.
TIP:
You may need to repeat this procedure numerous times until
you achieve acceptable output prints.
b. If the printed output for both Sides 1 and 2 is
acceptable, select OK to save and close the Profiles
window.
NOTE: Once you have selected OK to save and close the Profiles
window, the new profile procedure (for example,
AlignmentProfile2) can be selected from the Tray Properties
window whenever you want to run a job using this profile.
20.
Next:
Editing an existing Alignment profile
.
