Xerox DocuColor 5000 - Manual (Page 68)

DocuColor 5000 Administrator Guide 3-10
3. Profiles
Selecting the Magnification options
16.
Make the desired selection to the Magnification option. Use
this feature to correct for image stretch from Side 1 to Side
2. The image may be enlarged or reduced as necessary.
The factory default is zero (0).
TIP:
It is recommended that you choose only
one
Alignment
Profile feature (such as Registration), and then run a set of Test
Prints to evaluate the registration on that output. If you want
multiple Alignment Profile features selected, individually select
each feature, run Test Prints for that feature, and evaluate the
output. After you determine that the output for the selected
feature is acceptable, then you can select another Alignment
Profile feature to adjust.
17. Next: Running test prints .
These arrows indicate the
paper feed direction
Use these to make
the desired
selections. As you
click on the up or
down arrows, the
illustration moves
indicating the
direction that the
image will move on
the paper.
