Zebra Technologies Z SERIES 79695L-002 User Manual
Page 73
73
Configuration
Standard Control Panel Parameters
6/6/08
Z Series
®
/RZ™ Series User Guide
79695L-002 Rev. A
APL-D only
Set Module A Storage Device for APL-D
Default Value: NONE
Selections: NONE, RAM 1, RAM 2, FLASH 1, FLASH 2
To change the value shown:
1.
Press
SELECT
to select the parameter.
2.
Press
PLUS (+)
or
MINUS (-)
to scroll through the options.
3.
Press
SELECT
to accept any changes and deselect the parameter.
APL-D only
Set Module B Storage Device for APL-D
Default Value: NONE
Selections: NONE, RAM 1, RAM 2, FLASH 1, FLASH 2
To change the value shown:
1.
Press
SELECT
to select the parameter.
2.
Press
PLUS (+)
or
MINUS (-)
to scroll through the options.
3.
Press
SELECT
to accept any changes and deselect the parameter.
APL-I only
Set Printer Resolution for APL-I
Sets the dot size for backward compatibility with some older APL-I
printers.
Default Value: 5 MIL
Selections: 5 MIL, 10 MIL, 15 MIL
To change the value shown:
1.
Press
SELECT
to select the parameter.
2.
Press
PLUS (+)
or
MINUS (-)
to scroll through the options.
3.
Press
SELECT
to accept any changes and deselect the parameter.
Set Media Type
This parameter tells the printer the type of media that you are using (see
for more information). Selecting continuous
media requires that you include a label length instruction in your label
format (
^LLxxxx
if you are using ZPL or ZPL II).
When non-continuous media is selected, the printer feeds media to
calculate label length (the distance between two recognized registration
points of the inter-label gap, webbing, or alignment notch or hole).
Default Value: GAP/NOTCH
Selections: GAP/NOTCH, MARK, CONTINUOUS
To change the value shown:
1.
Press
SELECT
to select the parameter.
2.
Press
PLUS (+)
or
MINUS (-)
to scroll through the options.
3.
Press
SELECT
to accept any changes and deselect the parameter.
Table 12 • Printer Parameters (Page 5 of 26)
Language/Parameter
Action/Explanation
