109 Routine Maintenance
Cleaning Procedures
6/6/08 Z Series ® /RZ™ Series User Guide 79695L-002 Rev. A
4. See Figure 18 . Using the swab from the Preventive Maintenance Kit (part number 47362),
wipe along the upper cutting surface (
1
) and the cutter blade (
2
). In place of the
Preventive Maintenance Kit, you may use a clean swab dipped in a solution of isopropyl
alcohol (minimum 90%) and deionized water (maximum 10%). Allow the solvent to
evaporate.
Figure 18 • Cleaning the Cutter Module
5. Replace the cutter shield.
6. Plug the printer into its power source, and then turn on ( I ) the printer.
The lower cutter blade returns to its correct operating position.
7. If the cutter continues to perform unsatisfactorily, contact an authorized service
technician.
1
2
