19 Introduction
Control Panel
6/6/08 Z Series ® /RZ™ Series User Guide 79695L-002 Rev. A
Control Panel
The control panel contains the lights that indicate basic operation and the buttons that you may
need to press during basic operation. The control panel buttons and lights are labeled in
Figure 5 . Descriptions for each are located in Table 1 and Table 2 .
Figure 5 • Control Panel
1
Power LED
2
Pause LED
3
Error LED
4
Data LED
5
LCD
6
CANCEL button
7
PLUS ( + ) button
8
SETUP/EXIT button
9
MINUS ( – ) button
10
SELECT button
11
FEED button
12
PAUSE button
1 2 3 4
5
6
7
8
11
12
10
9
