Specifications
General Specifications
142
79695L-002 Rev. A
Z Series
®
/RZ™ Series User Guide
6/6/08
General Specifications
General Specifications
ZM400/RZ400
ZM600/RZ600
Height
13.3 in.
338 mm
13.3 in.
338 mm
Width
10.9 in.
278 mm
13.4 in.
341 mm
Depth
18.7 in.
475 mm
18.7 in.
475 mm
Weight (without options)
32.4 lbs.
15 kg
34.7 lbs.
16 kg
Electrical
90-265 VAC, 48-62 Hz, 5 Amps
(fused)
90-265 VAC, 48-62 Hz, 5 Amps
(fused)
Temperature
Operating
40° to 104°F
5° to 40°C
40° to 104°F
5° to 40° C
Storage
–40° to 140°F
–40° to 60°C
–40° to 140°F
–40° to 60°C
Relative
Humidity
Operating
20% to 85%, non-condensing
20% to 85%, non-condensing
Storage
5% to 85%, non-condensing
5% to 85%, non-condensing
Communication Interfaces
• USB 2.0
• bi-directional parallel
• serial data interface
• RS-232C, with DB9F connector
• Configurable baud rate (300 - 115,200 kB), parity, and data bits.
Stop bits can be set at 1 or 2
• Software (XON/XOFF), hardware (DTR/DSR, or RTS/CTS)
communication handshake protocols
• RS422/485 with optional adapter
• ZebraNet
®
Wireless Plus Print Server and Internal Wireless Plus Print
Server - 802.11b/g - compliant wireless print server
• ZebraNet
®
10/100 Print Server - Ethernet network print server (10BASE-T,
100BASE-TX)
Memory
16 MB DRAM memory (12 MB user available)
8 MB flash memory (2 MB user available)
Label formats accepted by
firmware
• ZPL II
• XML-Enabled ZPL
• EPL II (203 dpi ZM400 or ZM600 only)
• APL-I (203 dpi ZM400 or ZM600 only)
• APL-D (203 dpi ZM400 or ZM600 only)
