137 Troubleshooting
Printer Diagnostics
6/6/08 Z Series ® /RZ™ Series User Guide 79695L-002 Rev. A
FEED and PAUSE Self Test
Performing this self test temporarily resets the printer configuration to the factory default
values. These values are active only until power is turned off unless you save them
permanently in memory. If the factory default values are permanently saved, a media
calibration procedure must be performed.
To perform a FEED and PAUSE self test, complete these steps:
1. Turn off ( O ) the printer.
2. Press and hold FEED and PAUSE while turning on ( I ) the printer.
3. Hold FEED and PAUSE until the first control panel light turns off.
The printer configuration is temporarily reset to the factory default values. No labels print
at the end of this test.
