IES-1000 User’s Guide
IEEE 802.1Q Tagged VLAN Commands 10-11
Figure 10-8 Example: VLAN List Command Display
In the figure above “O" denotes “egress port”, “V” denotes “tagged” and “X” denotes “
untagged”.
vid 01 02 03 04 05 06 07 08 09
---- ---- ---- ---- ---- ---- ---- ---- ---- ----
1 O O O O
V X X X X X X X X
2 O O
X X X X X X X X X
3 O O O
X X V X X X X X V
