IES-1000 User’s Guide
15-4 Firmware Upload and Recovery
Figure 15-3 Database Edit Dialog
7. Select Normal Bootp to enable normal BOOTP/TFTP functions.
Figure 15-4 Enable BOOTP/TFTP
8. Restart the network module and press any key within three seconds to get the following screen.
Figure 15-5 Enter Debug Mode
9. Press any key at the “Press any key within 3 seconds to enter debug mode
………………” message, to enter the debug mode.
SDRAM Testing ...
Mac address 00:A0:C5:12:34:56
