IES-1000 User’s Guide
10-6 IEEE 802.1QTagged VLAN Commands
This command displays the static VLAN registration table. The following figure is an example of what is
displayed when you use this command.
Figure 10-2 Example: SVLAN List Command Display
For more information about the Svlan List command display, refer to the Svlan Setentry command (shown next).
10.6.6 SVLAN Setentry Command
Syntax:
192.168.1.1 vlan1q> svlan setentry
where
= A VLAN ID. Valid parameter range = [1 – 4094].
= A bridge port number.
Valid parameter range = [1 – 9].
= Registrar administration control flag.
Valid parameters = [fixed, forbidden, normal].
Select fixed to register a to the static VLAN table with
.
Select normal to confirm registration of the to the static
VLAN table with .
Select forbidden to block a from joining the static VLAN table
with .
= The tag control flag. Valid parameters = [tag, untag].
Select tag to add tags to outgoing frames.
Select untag if you do not want to tag outgoing frames.
This command adds or modifies an entry into the static VLAN table. Display your configuration by using the
Svlan List command. An example of a configuration is shown next.
Modify a Static VLAN Table Example
The following is an example of how to modify a static VLAN table.
vid port# ad_control tag_control
-------- ------- ------------ ------------
1
1 fixed Tag
2 normal UnTag
3 normal UnTag
2 1 normal UnTag
2 fixed UnTag
3 normal UnTag
3 1 normal UnTag
2 normal UnTag
3 fixed UnTag
