Xerox digital copier printer 5750 User Manual
Page 53
2
2-25
Network Setup options
Entire NDS Tree/Specified subtree [Entire NDS Tree]
By default, the DocuColor searches the entire NDS tree for DocuColor print queues.
This option lets you restrict the search for DocuColor print jobs to a subtree (the Print
Queue root) in which the DocuColor print queues have been defined. This makes the
search more efficient. Select
Entire NDS tree
if the tree is small. Select
Specified subtree
to restrict the search and specify the subtree.
If you select
Entire NDS tree
, choosing
OK
returns to PServer Setup. Proceed with Bind-
ery Setup (see page 2-26), set the Polling Interval (see page 2-30), or choose Exit
PServer Setup to return to the Service Setup menu.
Browse to the root
of the Print Queue
subtree.
This message is displayed if you selected
Specified subtree
in the previous option.
Choose
OK
to browse the NDS tree to the Print Queue subtree.
Browsing to find the Print Server object begins with the NDS tree that you selected
previously (with
Select NDS Tree
). In each subsequent browse screen, the top line repre-
sents your current container. The second line contains:
• A list of objects directly below your current location
• The symbol “
..
” to go up one level
• The symbol “
.
” to select the current container object (displayed in the top line)
without traveling down the tree
With an object selected, choose
OK
to travel down the tree, or choose “
..
” to go up the
tree. When you select an object and choose
OK
, that object is then displayed on the top
line, and the second line lists objects contained within.
When the container that contains print queues is displayed in the second line, choose
OK
. In the next screen, choose “
.
” and then choose
OK
to select the object in the top
line.
When the DocuColor displays the container name, choose
OK
to return to PServer
Setup.
Proceed with Bindery Setup (see page 2-26), set the Polling Interval (see page 2-30), or
choose Exit PServer Setup to return to the Service Setup menu.
