Token Ring Network Option

Back view of the DocuColor with the Token Ring option installed

Shut off the DocuColor before connecting it to any network device

.

N

OTE

:

Do not attach cable to both Token Ring connectors.

Token Ring connectors

STP

UTP

Ethernet connectors

!
