2-10 Setting up the DocuColor
If the Token Ring option is installed, you have these additional options:
T O ACCESS N ETWORK S ETUP OPTIONS :
1. Confirm that the network cable is connected to the DocuColor.
During Network Setup, the DocuColor queries the network for zones, servers, and
server-based queues. If you perform Network Setup without a connected and function-
ing network, default settings are used that may not fulfill your needs.
2. Choose Network Setup from the main Setup menu.
3. Choose Port Setup.
4. To use Ethernet, choose Ethernet Setup from the Port Setup menu, and enter the
appropriate settings.
5. If the Token Ring option is installed, choose Token Ring Setup and enter the appropri-
ate settings.
6. To print to the parallel port, choose Parallel Port Setup from the Port Setup menu, and
enter the appropriate settings.
7. When you have finished entering port settings, choose Exit Port Setup and then choose
Protocol Setup.
8. Enter the appropriate settings for the protocol or protocols you will use.
9. When you have finished entering protocol settings, choose Exit Protocol Setup and
then choose Service Setup.
10. Enter the appropriate settings for the services you will use.
The options are described in detail in the following pages.
For this Network or
Connection Type:
Use this Port Setup: Use this Protocol Setup: Use this Service Setup:
TCP/IP over Token Ring Token Ring Setup TCP/IP Setup: Token Ring Setup LPD Setup
Web Services Setup
Windows Setup
IPX/SPX over Token Ring Token Ring Setup IPX/SPX Setup PServer Setup (NDS,
Bindery, or both)
