2
2-18 Setting up the DocuColor
IPX/SPX Setup options
For protocols other than IPX/SPX, the frame type is automatically enabled and does
not require setup, as follows:
To configure the DocuColor for IPX/SPX protocols, choose IPX/SPX Setup from
the Protocol Setup menu.
Select Frame Types
Choose Select Frame Types. You must choose at least one frame type to enable
IPX/SPX protocols. The DocuColor supports the following frame types for
IPX/SPX:
• for Ethernet—Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP
• for Token Ring—Token Ring and Token Ring SNAP
The frame selection screen allows you to make multiple selections. Depending on
your Port Setup selection, only Ethernet frame types, only Token Ring frame types,
or all frame types are displayed. Press the line selection button beside each frame
type used on your IPX/SPX network. An asterisk (*) appears beside each selected
frame type. (Press the line selection button again to deselect a frame type.) Use the
arrow keys to scroll to additional frame types. The DocuColor binds to each frame
type as you select it.
When you have selected all the frame types used, choose Exit IPX/SPX Setup.
Clear Frame Types
If you selected several frame types by mistake, you can clear them all at once by
choosing Exit IPX/SPX Setup, then choosing IPX/SPX Setup and selecting Clear
Frame Types.
With this protocol: And these printing services:
This frame type is
automatically enabled:
TCP/IP with Ethernet LPD (Line Printer Daemon) Ethernet II
TCP/IP with Token Ring LPD (Line Printer Daemon) Token Ring SNAP
Exit Protocol Setup
TCP/IP Setup
IPX/SPX Setup
Protocol Setup
Exit IPX/SPX Setup
Select Frame Types
Clear Frame Types
IPX/SPX Setup
Exit IPX/SPX Setup
Ethernet 802.2 *
Ethernet 802.3
Ethernet II
IPX/SPX Setup
