Xerox digital copier printer 5750 - Manual (Page 51)

2
2-23 Network Setup options
Is user login needed
to browse NDS tree?
Yes/No [No]
Select No if no password is required to browse the tree. You can proceed to navigate to
the Print Server object (see page 2-24).
Select Yes if network permissions require that you log in to browse the NDS tree and
see the Print Server object you want to select. If you select Yes , you are prompted to
navigate to the User Login object.
Navigate the NDS
tree to the User
Login object.
This message is displayed if you selected Yes for the previous option. Choose OK and
browse the NDS tree as described in the following paragraphs.
NDS Tree name
Object list, “..”
Browsing to find the User Login object begins with the NDS tree that you selected
previously (with
Select NDS Tree ). Use the up and down arrow buttons to scroll a list of
objects in the tree beneath the [Root] in the hierarchy, or use the navigation symbol
“ .. ” to go up one level at a time.
In each subsequent browse screen, the top line represents your current location. The
second line contains:
• A list of objects in the current container directly below your current location
• The symbol “ .. ” to go up one level.
With an object selected, choose OK to travel down the tree, or choose “ .. ” to go up the
tree. When you select an object and choose OK , that object is then displayed on the top
line, and the second line lists objects directly below it.
Continue to browse the NDS tree until the User Login object is displayed in the sec-
ond line. Choose
OK .
