2-9 Network Setup options
Network Setup options
Network Setup configures the DocuColor to receive print jobs over the network
systems that will be used at your site.
If the DocuColor is configured to enable more than one protocol, it automatically
switches to the correct protocol when it receives a print job. When the parallel port and
one or two network ports are enabled, print jobs can be received over all of those ports
at the same time.
The available network types, and the Setup areas that pertain to them, are summarized
in the following tables.
In the Setup menu, choose Network Setup.
The Network Setup menu includes three submenus that let you choose port types,
protocols, and network services. You must perform Port Setup and enable at least one
port.
For each item you enable, you are prompted to enter settings for that item. Default
values, where applicable, appear in square brackets.
In Network Setup you specify network addresses and names to be used by
workstations, servers, and the DocuColor when they communicate with each other.
You need to display and select options only for the network systems that are currently
used at your site. If your network requirements change, you can change the Network
Setup at any time.
For this Network or
Connection Type:
Use this Port Setup: Use this Protocol Setup: Use this Service Setup:
TCP/IP over Ethernet Ethernet Setup TCP/IP Setup: Ethernet Setup LPD Setup
Web Services Setup
Windows Setup
IPX/SPX over Ethernet Ethernet Setup IPX/SPX Setup PServer Setup (NDS,
Bindery, or both)
Parallel Parallel Port Setup — —
Exit Setup
Server Setup
Network Setup
Printer Setup
Setup
Exit Network Setup
Port Setup
Protocol Setup
Service Setup
Network Setup
