Print language/mode/logical printer – Xerox 7232 User Manual

Page 89

UNIX TCP/IP Installation

Xerox WorkCentre 7232/7242 System Administration Guide

Print language/mode/logical printer

A printer name for the logical printer should correspond to the print language/mode to
be used for printing, or to the Logical Printer Number which was registered through
CentreWare Internet Services.

*:Requires PostScript Option Kit

You can also add output parameters to the above printer name. The parameters are
the same as those for -C option. Insert “_” between the printer name and output
parameter, for example “PS_A4”.

NOTE: If specifying a different printer name, the print language or mode specified on
the touch screen of the machine is used.

NOTE: When setting print languages/modes from the same workstation to a single
printer, it is recommended to set one kind of each. If two or more kinds of languages/
modes are set, the workstation may display the same job number for some queues
(lpq).

NOTE: To print an ASCII-format PostScript file, specify PSASC for data processing
with TBCP enabled.

NOTE: To print a binary-format PostScript file, specify PSBIN for data processing with
TBCP disabled.

NOTE: When specifying PS, the machine functions as if PSBIN is specified.

NOTE: You cannot use -C option when specifying the printer name with the output
parameter.

NOTE: For details about -C option, refer to -C Option on page 90.

NOTE: Lowercase characters can also be used for a printer name.

Printer Name

Print Language/Mode/Logical Printer

PS*

PostScript

PSASC/PSA*

PostScript

PSBIN/PSB*

PostScript

PCL

Print language specified on the touch screen of the machine.

DUMP/DMP

Dump mode

AUTO/ATO

Auto detection mode

TIFF/TIF

TIFF direct print

TIFF%n

TIFF (%n: Logical Printer Number 1 to 20 which were
registered through CentreWare Internet Services.)

PS%n*

PostScript (%n: Logical Printer Number 1 to 10 which were
registered through CentreWare Internet Services.)
