5 NetWare

Xerox WorkCentre 7232/7242 System Administration Guide

NOTE: Keep the SNMP protocol enabled while you use the machine on the TCP/IP
network.

NOTE: Some of the configuration options for this protocol are only available from
CentreWare Internet Services.

First, enable the NetWare protocol.

Connect the machine to the network.

Press the button on the control panel, and then type the Key
Operator login ID to enter the Key Operator mode.

NOTE: The passcode may also be required depending on the machine configuration.

Press the button on the control panel, and then select the
[Tools] tab on the screen.

Select [System Settings].

Select [Connectivity & Network Setup].

Select [Port Settings].

Select [NetWare], and then [Change Settings].

Select [Port Status], and then [Change Settings].

Select [Enabled], and then [Save].

Next, establish TCP/IP if you use IP Address for a NetWare network.

In [Connectivity & Network Setup], select [Protocol Settings].

Under [TCP/IP - IP Mode], select [IPv4 Mode] or [Dual Stack].

NOTE: [IPv6 Mode] is not available for Netware settings.

Select [IP Address Resolution], and then [Change Settings].

Select a method for establishing an IP address from [DHCP], [BOOTP], [RARP],
[DHCP/Autonet], and [STATIC], and then select [Save].

NOTE: Use the DHCP server together with the Windows Internet Name Server
(WINS) server.

If you selected [STATIC] in step 4, then proceed to step 5 to configure the protocol
settings. Otherwise, proceed to step 11.

Select [IPv4 - IP Address], and then [Change Settings].

Use the keypad on the screen to enter the IP Address for the machine in the
format “xxx.xxx.xxx.xxx”. Enter a value (0 to 255) into the highlighted field and
select [Next]. The next 3 digits are highlighted. When you have finished entering
all values, select [Save].

Select [IPv4 – Subnet Mask], and then [Change Settings].

Using the same method as in step 6, enter the Subnet Mask.

Select [IPv4 – Gateway Address], and then [Change Settings].
