UNIX TCP/IP Installation

Xerox WorkCentre 7232/7242 System Administration Guide

Network Communication Setup

Use this procedure to set up the network communication parameters of the machine.

NOTE: Keep the SNMP port enabled while you use the machine on the TCP/IP
network.

NOTE: Some of the configuration options for this protocol are only available from the
CentreWare Internet Services.

Follow the steps below to establish TCP/IP.

Connect the machine to the network.

Press the button on the control panel, and then type the Key
Operator login ID to enter the Key Operator mode.

NOTE: The passcode may also be required depending on the machine configuration.

Press the button on the control panel, and then select the
[Tools] tab on the screen.

Select [System Settings].

Select [Connectivity & Network Setup].

Select [Protocol Settings].

Under [TCP/IP - IP Mode], select [IPv4 Mode], [IPv6 Mode], or [Dual Stack].

When [IPv4 Mode] or [Dual Stack] is selected

Select [IP Address Resolution], and then [Change Settings].

Select a method for establishing an IP address from [DHCP], [BOOTP], [RARP],
[DHCP/Autonet], and [STATIC], and then select [Save].

NOTE: Use the DHCP server together with the Windows Internet Name Server
(WINS) server.

If you selected [STATIC] in step 9, then proceed to step 10 to configure the protocol
settings. Otherwise, proceed to step 16.

10.

Select [IPv4 - IP Address], and then [Change Settings].

11.

Use the keypad on the screen to enter the IP Address for the machine in the
format “xxx.xxx.xxx.xxx”. When you have finished entering all values, select
[Save].

12.

Select [IPv4 – Subnet Mask], and then [Change Settings].

13.

Using the same method as in step 11, enter the Subnet Mask.

14.

Select [IPv4 – Gateway Address], and then [Change Settings].

NOTE: If you do not wish to set the gateway address, leave this field blank.

15.

Using the same method as in step 11, enter the Gateway Address.

16.

To enable IPv4 – IP Filtering, use CentreWare Internet Services to register the IP
addresses that will not be allowed to access the machine.
