Front panel description Using the front panel
The LOCAL function key
This key is used for returning the Power Supply to LOCAL control (enabling
programming and set-up of its parameters from the front panel) after a remote device
has been controlling it.
During manual calibration, the LOCAL key is used for aborting the calibration
process.
The RESET function key
The RESET key is used for resetting faults and error indications:
Operating mode Cursor location Function
Module status Module symbol Reset any Power Module faults
and errors
System status System symbol Reset any system error or fault. If
the main converter has been
shutdown then the Power Supply
will undergo a full reset.
Module Setup Module symbol Reset the Power Module to its
power-on state
Sequence program
editing Any Initiate program erasure
Sequence program run Any Stop the program
The SYSTEM function key
The SYSTEM key is mainly a navigation aid and has the functions summarized in
the following table:
Operating mode Cursor location Function
Status mode Any Move the cursor to the system
symbol
Setup mode Any Move the cursor to the system
symbol
Module programming
- SET parameters Any Causes the output disconnect
relay to open or close (toggle
operation)
The OUT function key
The OUT function key controls the state of the Power Modules output:
Operating mode Cursor location Function
Module programming Any Toggle the individual output on or
off
