24 www.xilinx.com ML310 User Guide
1-800-255-7778 UG068 (v1.01) August 25, 2004
Chapter 2: ML310 Embedded Development Platform R
ddr_dqs[5] M29 DDR_DQS02 25
ddr_dqs[6] H29 DDR_DQS01 14
ddr_dqs[7] F29 DDR_DQS00 5
ddr_dq[0] AG28 DDR_DQ63 179
ddr_dq[1] AG26 DDR_DQ62 178
ddr_dq[2] AE26 DDR_DQ61 175
ddr_dq[3] AD26 DDR_DQ60 174
ddr_dq[4] AH27 DDR_DQ59 88
ddr_dq[5] AH26 DDR_DQ58 87
ddr_dq[6] AF25 DDR_DQ57 84
ddr_dq[7] AD25 DDR_DQ56 83
ddr_dq[8] AF28 DDR_DQ55 171
ddr_dq[9] AD28 DDR_DQ54 170
ddr_dq[10] AB25 DDR_DQ53 166
ddr_dq[11] AB26 DDR_DQ52 165
ddr_dq[12] AF27 DDR_DQ51 80
ddr_dq[13] AD27 DDR_DQ50 79
ddr_dq[14] AC25 DDR_DQ49 73
ddr_dq[15] AC26 DDR_DQ48 72
ddr_dq[16] AC27 DDR_DQ47 162
ddr_dq[17] AC28 DDR_DQ46 161
ddr_dq[18] AA26 DDR_DQ45 155
ddr_dq[19] Y26 DDR_DQ44 153
ddr_dq[20] AB27 DDR_DQ43 69
ddr_dq[21] AB28 DDR_DQ42 68
ddr_dq[22] AA25 DDR_DQ41 64
ddr_dq[23] Y27 DDR_DQ40 61
ddr_dq[24] W28 DDR_DQ39 151
ddr_dq[25] W25 DDR_DQ38 150
ddr_dq[26] V27 DDR_DQ37 147
ddr_dq[27] V25 DDR_DQ36 146
ddr_dq[28] W27 DDR_DQ35 60
ddr_dq[29] W26 DDR_DQ34 57
ddr_dq[30] V28 DDR_DQ33 55
ddr_dq[31] V26 DDR_DQ32 53
Table 2-1: Connections from FPGA to DIMM Interface, P7
UCF Signal Name
XC2VP30 Pin
(U37)
Schem Signal Name
DIMM
(P7)
