Verbose
Response
Terse
Response
Description
CONNECT 115200
19
Connection made at 115200 bps.
(Indicates software rate).
FAX
33
Fax Detected. (Fax/Data answer mode).
DATA
35
Modem detected. (Fax/Data answer mode).
CARRIER 300
40
Carrier rate of 300 bps.
CARRIER 1200
46
Carrier rate of 1200 bps.
CARRIER 2400
47
Carrier rate of 2400 bps.
CARRIER 4800
48
Carrier rate of 4800 bps.
CARRIER 7200
49
Carrier rate of 7200 bps.
CARRIER 9600
50
Carrier rate of 9600 bps.
CARRIER 12000
51
Carrier rate of 12000 bps.
CARRIER 14400
52
Carrier rate of 14400 bps.
CARRIER 16800
53
Carrier rate of 16800 bps.
CARRIER 19200
54
Carrier rate of 19200 bps.
CARRIER 21600
55
Carrier rate of 21600 bps.
CARRIER 24000
56
Carrier rate of 24000 bps.
CARRIER 26400
57
Carrier rate of 26400 bps.
CARRIER 28800
58
Carrier rate of 28800 bps.
COMPRESSION:
CLASS 5
66
The modem has connected in MNP class 5 and
COMPRESSION message reporting has been enabled.
COMPRESSION:
V.42BIS
67
The modem has connected in V.42bis and COMPRESSION
message reporting has been enabled.
COMPRESSION:
NONE
69
The modem has connected without data compression and
COMPRESSION message reporting has been enabled.
PROTOCOL:
NONE
76
The modem has connected without any form of error
correction. (NO MNP4 or V.42).
PROTOCOL:
LAPM
77
The modem has connected in the V.42 LAPM mode of error
correction.
PROTOCOL:
ALT
80
The modem has connected in the MNP4 mode of error
correction.
Notes:
• The CARRIER Result Code must be enabled using S95 bit 2 or the ATW1
command.
• The COMPRESSION Result Code must be enabled using S95 bit 5.
• The PROTOCOL Result Code must be enabled using S95 bit 3 or the ATW1
command.
