4.2.7. Default Security Mode Status (Sw8)
SetUp Switch eight selects the default enabled/disabled status for the Security Mode. The
Security Mode can also be disabled via the General Parameters Menu (/G). Note that if the
unit is reset to default parameters, the Security Mode feature will return to the default status
selected by SetUp Switch eight.
Note: If the Modem Security mode is disabled (off), all password and security
features will be suppressed, and you will not be able to access the SRM command
mode via modem (although Console Port access to command mode is still allowed).
When the Security Mode is disabled, the SRM will function like a normal non-
secure, modem
Security Mode Sw8
On * Down
Off Up
* = Factory Setting
4.3. Initialize Unit to Default Settings
If SetUp Switch settings are changed, new parameters will not take effect until the SRM-100 is
initialized.
CAUTION: After initialization, menu selected parameters will return to the
settings specified by the SetUp Switches and the Password Directory will also
be erased.
Note: To reset the SRM to default parameters without clearing the Password
Directory, use the "Default Parameters" option in the Utilities menu as described in
Section 7.5.4.
1. Set the SRM-100 Power Switch to the OFF position.
2. Press and hold the Default Button (located on the back panel). Place the SRM-100 Power
Switch in the ON position.
3. Wait for one second (or until the front panel LEDs flash), and then release the Default
Button.
