9.2. Modem Status
The SRM's internal modem can generate a status screen, which lists currently selected settings
for most of the AT commands, the contents of most of the S-Registers, the two stored modem
profiles, and four stored phone numbers.
To display the modem status screen, access the internal modem's command mode as described
in Section 9.1, then type AT&V and press [Enter]. The internal modem will display the status
screen shown in Figure 9.1 below.
9.3. AT Command Set
This section describes the AT command set. Note the following:
· Type commands in either upper or lower case. Do not use a combination of upper and
lower case characters.
· Use the Backspace key to delete errors.
· Some commands have numeric options. If these commands are invoked without a numeric
option, the modem will assume option 0 (zero). For example, when the command ATE is
invoked, the modem will assume command ATE0 was intended.
· All commands begin with the AT prefix, and are invoked by pressing [Enter] (Carriage
Return). The only exceptions are the A/ command (Repeat previous command) and +++
(Exit to on-line command mode).
· The maximum command length is 40 characters. This does not include the AT prefix,
Carriage Returns, or spaces.
· Defaults are marked with an asterisk (*).
9-2
SRM-100 - Secure Rack Modem, User's Guide Modem Command Set (AT Commands)
ACTIVE PROFILE
B1 E0 L1 M1 N1 Q1 T V1 W0 X4 Y0 &C1 &D2 &G0 &J0 &K3 &Q5 &R1 &S0 &T5 &X0 &Y0
S00:001 S01:000 S02:043 S03:013 S04:010 S05:008 S06:002 S07:050 S08:002 S09:006
S10:014 S11:095 S12:050 S18:000 S25:005 S26:001 S36:007 S37:000 S38:020 S44:020
S46:138 S48:007 S95:000
STORED PROFILE 0
B1 E1 L1 M1 N1 Q0 T V1 W0 X4 Y0 &C1 &D2 &G0 &J0 &K3 &Q5 &R1 &S0 &T5 &X0
S00:000 S02:043 S06:002 S07:050 S08:002 S09:006 S10:014 S11:095 S12:050 S18:000
S36:007 S37:000 S40:104 S41:195 S46:138 S95:000
STORED PROFILE 1
B1 E1 L1 M1 N1 Q0 T V1 W0 X4 Y0 &C1 &D2 &G0 &J0 &K3 &Q5 &R1 &S0 &T5 &X0
S00:000 S02:043 S06:002 S07:050 S08:002 S09:006 S10:014 S11:095 S12:050 S18:000
S36:007 S37:000 S40:104 S41:195 S46:138 S95:000
TELEPHONE NUMBERS
0= 1=
2= 3=
Figure 9.1: The Modem Status Screen (Defaults Shown)
