11. Modem Result Codes
When AT commands are invoked, the modem will respond with either Terse (numeric) or
Verbose (text) result codes. The result code format is set using the Modem Parameters Menu
(/M), or the ATVn command. Result Codes can also be completely suppressed by enabling the
Quiet Mode via the Modem Parameters Menu or the ATQn command.
Verbose
Response
Terse
Response Description
OK 0 Modem Successfully executed a command.
CONNECT 1 Connection made at 300 bps.
RING 2 Modem detected an incoming call.
NO CARRIER 3 Modem lost or could not detect a remote carrier signal within
the Register S7 time.
ERROR 4 Modem found an error in the command line.
CONNECT 1200 5 Connection made at 1200 bps.
NO DIALTONE 6 Modem did not detect a dial tone within 5 seconds after
going off-hook.
BUSY 7 Modem detected a busy signal.
NO ANSWER 8 Five seconds of silence was not detected when using the @
command in the ATD command.
CONNECT 0600 9 Connection made at 600 bps.
CONNECT 2400 10 Connection made at 2400 bps.
CONNECT 4800 11 Connection made at 4800 bps.
CONNECT 9600 12 Connection made at 9600 bps.
CONNECT 7200 13 Connection made at 7200 bps.
CONNECT 12000 14 Connection made at 12000 bps.
CONNECT 14400 15 Connection made at 14400 bps.
CONNECT 16800 59 Connection made at 16800 bps.
CONNECT 19200 16 Connection made at 19200 bps. (If modem is set to respond
with connect message that indicates carrier rate, otherwise
indicates software rate).
CONNECT 21600 61 Connection made at 21600 bps.
CONNECT 24000 62 Connection made at 24000 bps.
CONNECT 26400 63 Connection made at 26400 bps.
CONNECT 28800 64 Connection made at 28800 bps.
CONNECT 38400 17 Connection made at 38400 bps. (Indicates software rate).
CONNECT 57600 18 Connection made at 57600 bps.
(Indicates software rate).
11-1
